MUSYSIC MU-L31F Professional LED PAR Light
The MUSYSIC MU-L31F is a compact, high‑efficiency LED PAR stage light designed for DJs, small venues, churches, parties, and event lighting setups. Featuring a powerful 30W RGB LED engine, 7‑channel DMX512 control, multiple auto programs, and a durable aluminum shell, the MU‑L31F delivers bright, vibrant color mixing with professional reliability.
Key Features
-
30W RGB LED: High‑output single RGB LED for smooth, rich color mixing.
-
7‑channel DMX512 control: Full control over dimming, speed, macros, and color.
-
Multiple operating modes: Auto, Master/Slave, DMX512, Sound‑activated.
-
Internal programs: Solid color, jump, rainbow, sound active, strobe, auto run, scrolling.
-
Aluminum housing: Lightweight, durable, and ideal for heat dissipation.
-
Linear 0–100% dimming: Smooth fades and transitions.
-
LED display with menu buttons: Easy DMX addressing and mode selection.
-
Wide beam angle: 25° standard (15° or 45° optional).
-
Compact & lightweight: Only 30W power consumption.
DMX Channel Functions (7CH)
-
CH1 – Macro Programs: A1–A5 color macros.
-
CH2 – Color Selection: Red, Green, Blue, Yellow, Cyan, Purple, White, and combinations.
- CH3 – Speed Adjustment
- CH4 – Master Dimmer
- CH5 – Red Dimming
- CH6 – Green Dimming
- CH7 – Blue Dimming
Operating Modes
-
A1: Static color mode
-
A2: Jump color change
-
A3: Rainbow mode
-
A4: Sound‑activated mode
-
A5: Strobe mode
-
A6: Auto run
-
A7: Scrolling effect
Technical Specifications
-
Control Channels: 7 DMX channels
-
Beam Angle: 25° (optional 15° or 45°)
-
Control Modes: Auto, Master/Slave, DMX512
-
Working Temperature: -20°C to 40°C
-
Color Mixing: RGB
-
Housing: Aluminum shell
-
IP Rating: IP20 (indoor use only)
-
Power Supply: AC 100–240V, 50/60Hz
-
LED Source: 30W RGB LED
-
Power Consumption: 30W
Ideal Applications
- DJ lighting
- Small stage and concert lighting
- Churches & worship events
- Bars, lounges & clubs
- Weddings & private parties
- Uplighting & wall wash
- Event production
The MUSYSIC MU-L31F is a compact yet powerful LED PAR fixture that delivers professional lighting performance with flexible control options and a wide range of built‑in effects—perfect for DJs, venues, and event professionals who need reliable, dynamic lighting in a lightweight package.
